Resources:
Datasheet:
www.dialight.com/Assets/Brochures_And_Catalogs/Illumination/MDTFHZSALEUX001.pdf•
Case Studies, IES Files, LM79 Reports:
www.dialight.com/Document/Index/710SafeSite
®
LED Area Light
Part Number
1
Initial Fixture
Lumens
Wattage
Lumens
Per Watt
Input Voltage
Lens
Light Distribution
HZA9C2N
6,000
58
103
110 - 277V AC
Toughened Glass
360
HZA8C2N
5,600
58
97
110 - 277V AC
Toughened Glass
180
HZA5C2N
5,100
47
108
110 - 277V AC
Toughened Glass
360
HZA4C2N
4,600
47
97
110 - 277V AC
Toughened Glass
180
HZA3C2N
4,000
38
105
110 - 277V AC
Toughened Glass
360
HZA2C2N
3,600
38
95
110 - 277V AC
Toughened Glass
180
HZA1C2N
2,200
21
105
110 - 277V AC
Toughened Glass
360
HZA0C2N
2,200
21
105
110 - 277V AC
Toughened Glass
180
1
Part numbers listed in the above table are cool white. For neutral white models replace the 5th character with an
N
e.g.: HZA2
C
2N becomes HZA2
N
2N
Lumens
Wattage lm/W Mounting Heights
6,000
58
103
6m
5,600
58
97
5,100
47
108
4,600
47
97
4,000
38
105
3,600
38
95
2,200
21
105
3m
Dimensions
Ratings and Certifications
•
L70 >100,000 hours @ 25°C ambient
•
ATEX / IECEx Zone 1, 21
•
ATEX / IECEx Zone 2, 22
•
CE
•
IP66
•
5yr full performance warranty
•
Junction box models available
Comparison
Warranty
L-70 T - Rating
Dialight Area Light
5yr
>100,000
T5
Metal Halide
1
15,000
T2
High Pressure Sodium 1
20,000
T2A
Light Distribution
360° Optical Pattern
180° Optical Pattern at 45°
Dimensions in mm
SafeSite
Specifications
Fixture Weight:
6.58kg
Housing:
Powder coated A360 aluminium
Voltage Range:
110 – 277V AC
Lens Options:
Toughened glass
Operating Temp.:
-40°C to +65°C
CRI:
70
Power Factor:
>0.9
CCT:
5000K (cool white)
THD:
<20%
4000K (neutral white)
Surge Protection:
EN61000-4-5
1 kV line to line
2 kV line to ground
Optics:
180° forward throw
360° forward throw
24
